Renogy 12V 300Ah Ultra-Lightweight LiFePO4 Lithium Battery

Description

12V 300Ah Ultra-Lightweight LiFePO4 Lithium Battery – 25kg Compact Design

The 12V 300Ah LiFePO4 Lithium Battery is a high-capacity, ultra-lightweight power solution designed for both mobile and stationary energy systems. Weighing just 25kg—57% lighter than comparable 200Ah lead-acid batteries—this compact unit delivers outstanding performance while saving space and reducing vehicle load.

Equipped with Grade-A prismatic LiFePO4 cells, the battery provides 5000+ cycles at 80% depth of discharge (DOD), ensuring years of reliable, maintenance-free operation. Its low-temperature protection system safeguards charging below 0°C and discharging below -20°C, making it suitable for all-weather use.

The compact footprint is 31% smaller than standard 12V 300Ah batteries, while its expandable design (up to 61.44kWh in 4P4S configuration) makes it versatile for RVs, campervans, marine systems, off-grid solar storage, and backup energy applications. Certified to international safety standards and backed by a 5-year warranty, this battery offers dependable, eco-friendly energy storage.

Please allow 5 to 10 working days for delivery.

Product Specifications:

• Rated Capacity (0.5C, 25°C): 300Ah

• Nominal Voltage: 12.8V

• Energy: 3840Wh

• Dimensions (L × W × H): 384 × 194 × 253 mm (15.12 × 7.64 × 9.96 in)

• Weight: 25.0 kg / 55.1 lbs

• Terminal Bolt Size: M8 × 1.25 × 12 mm & M8 × 1.25 × 16 mm

• Cycle Life (0.5C, 25°C): 5000+ cycles (80% DOD, 80% EOL)

• Charge Voltage: 10V – 14.8V

• Maximum Continuous Charge Current: 150A

• Maximum Continuous Discharge Current: 200A

• Peak Discharge Current: 380A (10s max)

• Charge Temperature Range: 0°C to 60°C (32°F to 140°F)

• Discharge Temperature Range: -20°C to 65°C (-4°F to 149°F)

• Storage Temperature Range: -20°C to 60°C (-4°F to 140°F)

• Operating Humidity: 5% – 95%

• Protection Rating: IP65

• Certifications: MSDS, UN38.3, FCC, CE, PSE, RCM, RoHS, UKCA

• Warranty: 5 Years

Download User Guide
